HP 16" ZBook Studio G9 Mobile Workstation - Manual (Page 31)

QuickSpecs
HP ZBook Studio 16 ” G9 Mobile Workstation PC
Technical Specifications – Networking
c08143475 — DA – 17017 — Worldwide — Version 4 — August 10, 2022 Page 31
AUDIO
HD Stereo Codec Realtek ALC3315
Audio I/O Ports Headset: CTIA only and Headphone-out
Internal Speaker
Amplifier
Cirrus Logic High-Efficiency Boosted Class D Amplifier
Multi-streaming Capable Playback multi-streaming can be enabled in the audio control panel to allow independent audio.
Following MSFT Behaviour
Sampling DAC: 44.1k/48kHz
ADC: 48kHz
Wavetable Syntheses
Analog Audio Support 3.5mm Headset: CTIA only and Headphone-out
# of Channels on Line-
Out
Internal Speaker Yes
FINGERPRINT SENSOR
Sensor vendor Synaptics FS7604
Sensor type Capacitive
DPI resolution 363DPI
Scan area 7.4x6mm sensor area
False Rejection Rate <1%
False Acceptance Rate 1:50K FAR
Mobile Voltage Operation Mobile Voltage Operation: 3.0V to 3.6V
Operating Temperature Operating Temperature: 0~60°C
Current Consumption
Current Consumption Image : 100mA Max
Low Latency Wait For
Finger
Low Latency Wait For Finger: 260 uA
Capture Rate Capture Rate: <30msec per image
ESD Resistance ESD Resistance: IEC 61000-4-2 4B (+/-15KV)
Detection Matrix Detection Matrix: 363 dpi / 7.4x6mm sensor area
POWER
HP 150W Slim 4.5 mm
PFC Right Angle Smart
(3-pin) AC Power Adapter Dimensions 138x66x22mm
Weight unit: 325g +/- 10g
Input Input Efficiency 88% at 115 Vac and 89% at 230Vac
Input frequency range 47 ~ 63 Hz
Input AC current 2.7 A at 90 Vac and Maximum Load
Output Output power 150W
DC output 19.5V
Hold-up time 5ms at 115 Vac input
Output current limit <16.0A
