QuickSpecs
HP ZBook Studio 16
”
G9 Mobile Workstation PC
Features
c08143475
—
DA
–
17017
—
Worldwide
—
Version 4
—
August 10, 2022
Page 9
DOCKING
Docking station model #1
HP Thunderbolt Dock G2
Total number of supported
displays (incl.the notebook)
display)
4
Max.resolutions supported
Dual 4K @30Hz or dual 4K UHD @ 60Hz is supported
Single 8K@ 30Hz (multiple tiles) for Thunderbolt hosts
Non-TBT hosts DP 1.4 in high res mode(1) 8K video single cable@30Hz
Dock Connectors
2xDP, 1xVGA, 1xTB, 1xUSB-C alt-mode
Technical limitations
Thunderbolt Hosts:
Maximum of (4) displays with maximum resolution of 5K@ 30Hz running Thunderbolt host.
Max resolution possible is dual 8K displays @ 60Hz running Thunderbolt host or running a
non-Thunderbolt host in High Resolution mode @30Hz
Non-Thunderbolt hosts:
The highest resolution for dual displays running a non-Thunderbolt host in multi-function
mode is
(1) 5K dual cable (using both DP ports) +(1) 4K on USB-C DP port
Non-Thunderbolt hosts support (3) displays with a max resolution of: (2) 5K single cable +
(1) 4K UHD @ 60 Hz in high resolution mode. In multi-function mode the maximum
resolution for (3) displays is (2) 5K single cable @ 30Hz + (1) 4K UHD @ 30Hz.
Docking station model #2
HP USB-C Dock G5
Dimensions (L x W x H)
4.80 x 4.80 x 1.77 in (122 x 122 x 45 mm)
Weight
1.49 lb (0.68 kg)
Top components
LED and power button to power or wake host system
1
Front components
One USB-CTM port with data and power out (15W) One USB-CTM cable to connect to host
system (1 meter cable length)
Side components
Two USB 3.0 charging ports One combo audio jack
Back components
Two USB 3.0 charging ports Two DisplayPort
TM
ports One 10/100/1000 RJ 45 port One HDMI
2.0 port One standard lock slot
External monitor support
Power to system
3 displays is the maximum displays supported, depending on the capabilities of the host
machine. Triple 4K displays requires a DP 1.4 machine with DSC** in high res mode. See
QuickSpecs for configurations supported at:
Power to host
(USB-C PD) 5V , 9V, 10V, 12V, 15V, 20V all at 5A MAX
