HP 16" ZBook Studio G9 Mobile Workstation - Manual (Page 7)

QuickSpecs
HP ZBook Studio 16 ” G9 Mobile Workstation PC
Features
c08143475 — DA – 17017 — Worldwide — Version 4 — August 10, 2022 Page 7
CHIPSET
Integrated in the processor
INTEL® CORE™ i7 WITH VPRO®/CORE i9 WITH VPRO® TECHNOLOGY CAPABLE
Intel® Core™ i7 with vPro ® , Core™ i9 with vPro ® technology is a selectable feature that is available on units configured with
select processors, a qualified Intel® WLAN module and a preinstalled Windows® operating system. It provides advances in
remote manageability, security, energy efficient performance, and wireless connectivity. Intel® Active Management
Technology (iAMT) offers built-in manageability and proactive security for networked mobile workstations, even when they
are powered off* or when the operating system is inoperable. It can help identify threats before they reach the network,
isolate infected systems, and update regardless of their power state.
1,2
1 Requires a Windows operating system, network hardware and software, connection with a power source, and a direct (non-
VPN) corporate network connection which is either cable or wireless LAN.
2 Intel vPro® requires Windows 10 Pro 64 bit or higher, a vPro supported processor, vPro enabled chipset, vPro enabled wired
LAN and/or Wi-Fi 6E WLAN and TPM 2.0. Some functionality requires additional 3rd party software in order to run. Features of
vPro® Essentials and Enterprise vary. See
http://intel.com/vpro
GRAPHICS
Integrated
Intel® Iris® X ᵉ Graphics
Discrete
NVIDIA RTX ™ A1000 Laptop GPU (4GB GDDR6 dedicated)
NVIDIA RTX ™ A2000 8GB Laptop GPU (8GB GDDR6 dedicated)
NVIDIA RTX ™ A3000 12GB Laptop GPU (12GB GDDR6 dedicated) 6
NVIDIA RTX ™ A4500 Laptop GPU (16GB GDDR6 dedicated) 6
NVIDIA RTX ™ A5500 Laptop GPU (16GB GDDR6 dedicated) 6
NVIDIA GeForce 3060 Laptop GPU (6GB GDDR6 dedicated)
NVIDIA GeForce 3070 Ti Laptop GPU (8GB GDDR6 dedicated)
NVIDIA GeForce 3080 Ti Laptop GPU (16GB GDDR6 dedicated)
Supports
Support HD decode, DX12, HDMI 2.0b, HDCP 2.3
Hybrid Graphics supported (Default)
1 UHD content required to view UHD images.
2 Both UMA & Discrete configurations support up to 4 displays when on the HP Thunderbolt Dock G2 (sold separately) – Max.
resolution = 2.5K @60Hz (DP1) & 2.5K @60Hz (DP2) & FHD (VGA) OR 4K @60Hz (one DP Port) & 4K @60Hz (Type-C® output
port using a Type C®-to-DP adapter).
3 Support HD decode, DX11, DX12, HDMI 1.4, HDCP 2.3 via DP up to 4K @ 60Hz and via HDMI up to 4K @ 30Hz
4 Shared video memory (UMA) uses part of the total system memory for video performance. System memory dedicated to
video performance is not available for other use by other programs.
5 GPU configurations may be limited to specific GPU/Memory Configurations.
6 NOTES:
NVIDIA Feature: Discrete Graphics (RTX A3000, A4500, A5500) can turn “ECC ON” with the VRAM
