Connecting speakers or other audio receivers
To connect speakers or other audio receivers with an audio cable (not provided):
1. Use an audio cable to connect the digital audio in port of the audio receiver device to the
DIGITAL AUDIO OUT
port of
the TV.
2. Plug the connected devices into the main power socket before switching on the TV.
TIP:
If you prefer to use Audio Return Channel, then see
Connecting a digital sound bar to use Audio Return Channel (ARC)
.
NOTES
•
When a digital audio system is connected to the
DIGITAL AUDIO OUT
port, decrease the TV and system volume.
•
You can connect the
DIGITAL AUDIO OUT
port on the back of the TV to the Optical port on the Amplifier. Then go to
the
Settings
/
Menu
>
Sound
>
Advanced Settings
>
Digital Audio Out
to select
Dolby Digital
to receive the Dolby Digital
audio.
Connecting a digital sound bar to use Audio Return Channel (ARC)
If you’d like to use the Audio Return Channel (ARC) feature to have sound sent from the TV back down an HDMI cable
to a digital sound bar, then you will need to connect the cable to the
HDMI / ARC
port. By using this feature, you will also
be able to control the sound bar with your TV remote instead of using multiple remotes for each device.
To connect a digital sound bar with an HDMI cable (not provided):
1. Connect the cable that’s attached to the sound bar to the
HDMI / ARC
port on the TV.
2. Turn on the sound bar by pressing the Power button.
3. Press the
[
]
button on your remote and select the
Settings
icon, then go to
Sound
>
Audio Output
.
4. Select the
ARC
option.
NOTES
•
Only digital sound bars that require a wired connection are compatible with the TV.
•
If the device has an Input Selector feature then make sure to change it to TV.
•
5.1 CH (channel) audio is available when the TV is connected to an external device that supports a 5.1 channel
surround sound. You can go to the
Settings
/
Menu
>
Sound
>
Advanced Settings
>
Digital Audio Out
to select
Dolby
Digital Plus
to receive the 5.1 channel audio. You will need to also go into the sound or audio settings of your
device to ensure it is set to 5.1 Channel output. It may read ‘Bitstream’, ‘RAW’ or ‘Digital’.
EXTERNAL DEVICES
Powerless
Bass Speaker
Speaker
Digital Sound Bar
Audio Amplifier
DIGITAL
AUDIO OUT
TV PORT
Audio Cable
HDMI ARC
HDM
I
EXTERNAL DEVICE
TV PORT
HDMI Cable
Digital Sound Bar
Audio Amplifier
