A CLOSER LOOK
CLASSIC 300D MACHINE SPECIFICATIONS
Rated DC Output (1)
DC Current
Product
Ordering
Current / Voltage /
Fine Adjustment
Auxiliary
Dimension &
Weight
Name
Information
Description
Duty Cycle
Range
Power (2)
H(3) x W x L
lbs (kg)
Classic
®
300D
K1643-7
300 Amp DC
NEMA Ratings
40 - 350 Amps
3,000 Watts
45.5 x 24.0 x 65.0 in
1354
(Perkins
®
)
Arc Welder
250A / 30V / 100%
60 Hz, AC
(1156 x 610 x 1651mm)
(614)
300A / 32V / 60%
220 - Max
K1643-8
All Copper
160 - 240
20 Amps @
w/ Wire Feed Module
Windings
98V DC
120 - 190
115V
45.5 x 24.0 x 65.0 in
1389
(Perkins
®
)
MAX OCV
80 - 130
with GFCI
(1156 x 610 x 1651mm)
(630)
Pure DC Power
Min - 90
Generator
13 Amps @
K1643-9
230V
45.5 x 24.0 x 66.5 in
1329
w/ Custom Arc
®
(1156 x 610 x 1727mm)
(603)
(Kubota
®
)
K1643-10
45.5 x 24.0 x 66.5 in
1364
w/ Custom Arc
®
(1156 x 610 x 1727mm)
(619)
& Wire Feed Module
(Kubota
®
)
CLASSIC
®
300D ENGINE SPECIFICATIONS
Engine
Horsepower &
Operating
Fuel
Model
Description
Displacement
Ignition
Capacities
Speeds
Consumption
Perkins
®
4 Cylinder
32.7 HP
FUEL:
FULL LOAD
1.4 Gals/Hr
404D-22
4 Cycle
@ 1800 RPM
Compression
15 Gals (57 Ltrs)
300A (1725 RPM)
5.2 Ltr/Hr
Diesel (4)
Water-Cooled
Ignited
EPA Tier 4i
Diesel Engine
135.4 cu in
OIL:
HIGH IDLE
0.4 Gals/Hr
Cast Iron Cylinders
(2.2 ltrs)
8.5 Qts (8.0 Ltrs)
1,800 RPM
1.6 Ltr/Hr
Block/Crank Case
Mechanical Governor
COOLANT:
LOW IDLE
0.3 Gals/Hr
9.5 Qts (9.0 Ltrs)
1,400 RPM
1.1 Ltr/Hr
Kubota
®
4 Cylinder
32.5 HP
V2403M
4 Cycle
@ 1800 RPM
Compression
FUEL:
FULL LOAD
1.3 Gals/Hr
Diesel (5)
Water-Cooled
Ignited
15 Gals (57 Ltrs)
300A (1800 RPM)
5.0 Ltr/Hr
EPA Tier 4i
Diesel Engine
149 cu in
Cast Iron Cylinders
(2.4 ltrs.)
OIL:
HIGH IDLE
0.5 Gals/Hr
Block/Crank Case
8.0 Qts (7.6 Ltrs)
1,650–1800 RPM
1.7 Ltr/Hr
Electronic Governor
with custom arc dial
COOLANT:
LOW IDLE
0.3 Gals/Hr
9.5 Qts (9.0 Ltrs)
1,400 RPM
1.1 Ltrs/Hr
(1) Based on a 10 minute period. High Altitude: Perkins
®
- For maximum rating, derate the output 2.5% to 3.5% for every 1,000 ft. (300 m). Kubota – for maximum rating, derate
the output 4% for every 1,000 ft (300 m) above 4,900 ft (1500 m).
(2) 115V will operate either 60 Hz, or 50/60 Hz power tools, lights, etc.
(3) Height is to top of exhaust elbow.
(4) Perkins
®
warranty is 2 years/2,000 hours, all components, 3 years major components. See warranty for details.
(5) Kubota
®
engine warranty for U.S. and Canada is 2 years/2,000 hours, 3 years major components. Some limitations exist for Canada. See warranty statement for details.
