Classic ® 300D
www.lincolnelectric.com [7]
RECOMMENDED OPTIONS
WIRE FEEDER OPTIONS
Wire Feed Module
Provides constant voltage (CV)
output with excellent arc stability
for Innershield welding and MIG
welding. Easy installation.
Recommended wire feeders are the
LN-25 and the LN-23P.
Order K623-1
Remote Control Kit
(Stick & Wire)
For Classic & Pipeliner machines
that have the wire feed module.
Contains a rheostat for stick
output, a potentiometer for wire
output and 100 ft. (30.5m) of
control cable.
Order K2464-1
LN-25 PRO Wire Feeder
Portable CC/CV unit for flux-cored
and MIG welding with MAXTRAC
®
wire drive system. Includes Gas
Solenoid & Internal Contactor.
Requires Wire Feed Module.
Order K2613-1
Magnum ® 350 Innershield ® Gun
(for LN-25 PRO)
For self-shielded wire with 15 ft.
(4.5 m) cable. For .062"-3/32"
(1.6-2.8 mm) wire.
Order K126-2
Drive Roll and Guide Tube Kit
(for LN-25 PRO,)
For cored or solid steel wire.
Order KP1697-068
for .068"-.072" (1.8 mm)
KP1697-5/64
for 5/64" (2.0 mm)
Magnum ® 300 MIG Gun
For .035"-.045" (0.9-1.2 mm)
gas-shielded wire with 15 ft.
(4.5m) cable.
LN-25 PRO
Order K1802-1
(includes Connector Kit)
Drive Roll and Guide Tube Kit
(for LN-25 PRO)
For .035" and .045" (0.9-1.1 mm)
solid steel wire.
Order KP1696-1
WIRE FEEDER CONT.
LN-23P Wire Feeder
Portable CV unit for Innershield
pipe welding. Includes drive rolls
and guide tubes. Requires K2393-1
or -2 Input Cable Assembly and
Magnum
® Innershield ® Gun.
Order K316L-2
Input Cable Assembly
for LN-23P
8-socket to 14-pin control cable
with lugged electrode cable for
K316L-2 LN-23P Wire Feeder.
Order K2393-1 25 ft. (7.6 m)
K2393-1 75 ft. (22.9 m)
Magnum ® 350 Innershield ® Gun
(for LN-23P)
Rated 350 amps, 60% duty cycle.
For .068"-5/64" (1.7-2.0 mm)
Innershield
® wire and includes
reduced speed switch. Order
K345-10
Magnum ® SG Spool Gun
Hand held semiautomatic wire
feeder. Requires SG Control
Module.
Order K487-25
SG Control Module
The interface between the power
source and the spool gun. Provides
control of the wire speed and gas
flow. For use with a spool gun.
Order K488
Input Cable
(For SG Control Module)
For Lincoln engine power sources
with 14-pin MS-type connection,
separate 115V NEMA receptacles
and output stud connections.
Order K691-10
