Classic ® 300D
www.lincolnelectric.com [6]
RECOMMENDED OPTIONS
GENERAL OPTIONS
Power Plug Kit
Provides two 115V plugs rated at
20 amps each, and two 230V plugs
rated at 15 amps each. 115V plugs
may not be compatible with
common household receptacles.
Order K802D
Spark Arrestor Kit
Attaches to muffler exhaust tube.
Virtually eliminates spark emissions.
Order K903-1
Medium Welder Trailer
For heavy-duty road, off-road, plant
and yard use. Includes pivoting jack
stand, safety chains, and 13"
wheels. Stiff .120" welded
rectangular steel tube frame
construction is phosphate etched
and powder coat painted for
superior rust and corrosion
resistance. Low sway suspension
gives outstanding stability with
manageable tongue weight. Wheel
bearings are packed with high
viscosity, high pressure, low
washout Lubriplate
® grease.
Includes a Duo-Hitch ™ – a 2"
Ball/Lunette Eye combination
hitch. Overall width: 60".
Order:
K2636-1 Trailer
K2639-1 Fender
& Light Kit
K2640-1 Cable Rack
Service Indicator Kit
Provides a GO/NO-GO visual
indication of air cleaner element
useful service life. Filter service
based on restriction readings allows
the longest life possible from the
filter and best engine protection.
Order K1858-1
Stainless Steel Sheet Metal Kit
Stainless steel roof and doors. Also
includes decals (mounted), door
latches, door hooks, bumpers and
all required mounting hardware. Fits
K6090-9 and -10 Pipeliner
® 200D
and K1643-1 thru -10 Classic ® 300D
Order K2423-1
STICK OPTIONS
Accessory Kit
For Stick welding. Includes 35 ft.
(10.7m) 2/0 electrode cable with
lug, 30 ft. (9.1m) 2/0 work cable
with lugs, headshield, filter plate,
work clamp and electrode holder.
400 amp capacity.
Order K704
Remote Control Kit
Contains remote control rheostat,
and 100 ft. (30.5m) control cable.
Order K924-5
TIG OPTIONS
PTA-26V TIG Torch
Air-Cooled 200 amp torch
equipped with valve for gas flow
control. 25 ft. length.
Order K1783-9
Magnum ® Parts Kit for PTA-26V
TIG Torch
Magnum
® Parts Kit provides all the
torch accessories you need to start
welding. Parts kit provides collets,
collet bodies, a back cap, alumina
nozzles and tungstens in a variety
of sizes, all packaged in an easy to
carry reclosable pack.
Order KP509
TIG Module
Portable, high frequency unit with
gas valve for TIG welding. Rated at
300 amps/60% duty cycle.
Order K930-2
Control Cable
Connects welder and TIG Module
controls.
Order K936-4
Control Cable Extension
Allows the TIG Module to be
operated at distances up to 200 ft.
(61.9m) from the power source. 45
ft. (13.7m) length.
Order K937-45
Arc Start ™ Switch
Needed if an Amptrol ® is not used
when TIG welding. Comes with a
25 ft. (7.6m) cable. Attaches to the
TIG torch for convenient finger
control.
Order K814
Contactor Kit
For use with TIG Module and
Classic 300D.
Order K938-1
Water Valve Kit
For use with a water-cooled TIG
torch. Installs inside of TIG Module.
Order K844-1
115 Volt
