Typical Balanced Output Set-up
This image details a typical stereo output layout. Note the use of the Balanced XLR Jacks on both
the mixer and the amplifier. Always use the balanced output jacks whenever possible. The balanced
output jacks should always be used for cable runs in excess of 10 feet.
Using the balanced jacks will ensure a clean signal through out the entire audio system.
Typical Stereo Set-Up (Output)
Figure 9
©
