20
2.1.4 Do not use the charger to power electrical
equipment, vehicles or other external devices.
2.1.3 This device is not intended to be used by
persons (including children) with limited
physical, sensory or mental capacities or
lacking experience and / or knowledge unless
supervised by a person responsible for their safety
or instructed by such on how to use the
equipment.
2.1.2 Keep these instructions throughout the
product
' s life.
2.1.1 Keep charger away from
children! Children do not understand or
recognize the potential risks associated
with hand-ling electrical equipment. Never allow
the charger to end in the hands of children and
store out of the reach of children. Children may
swallow or choke on small parts. Children may be
injured when using the charger. Keep packaging
away from children.
Warning!
Read all instructions! Failure to follow safety
instructions may result in property damage,
personal injury or death! Keep these instructions
for reference. Keep this operator
' s manual for
future reference and include when passing on the
equipment to others. Make these instructions
accessible to third parties. The operator
' s manual
is a part of the equipment.
2.1 General safety notices
2.0 SAFETY
NOTICES
▪ Charger for all popular 6, 12 and 24 V
automotive batteries (AutoSelect function /
automatic battery recognition)
▪ Max. charging current 10 A
▪ Microprocessor
▪ Smart 6-setting charging mode
(IOIUOUOIUOa curve)
▪ No battery removal required (please refer to
Item 2.3 on page 22 and 23!)
▪ Automatic charging level adjustment.
Fully automatic charging, diagnostic, rescue
and maintenance function
▪ With display (charging status, battery voltage
and error messages)
▪ Battery charging status displayed as percentage
and as a bar graph. Holder for clamps and
practical cable storage compartment
1.5 LP 10.0 charger features
Connecting the charger
▪ First connect the positive (+) red
clamp to the positive (+) battery terminal.
▪ Now connect the negative (-) black
clamp to the negative (-) battery terminal.
▪ Only now plug the power plug into a
suitable 230 V alternating current outlet.
Disconnecting the charger
▪ First unplug the power cable from the mains.
▪ Then disconnect the negative (-) black
clamp from the negative (-) battery terminal.
▪ Then disconnect the positive (+) red clamp from
the positive (+) battery terminal.
1.4 Connecting and disconnecting the
LP 10.0 charger
