5.1.5 When storing the charger only loosely fold
cables and store in the charger
' s storage shelf
to avoid damage to the cable.
Secure battery clamps to the designated brackets
inside the left and right charger compart-
ment (see page 24, figure 1).
32
3
4 1
° °
~
Device description: Charger LP 10.0
Item number:
97100
Dimensions: approx. 270 x 150 x 190
mm (l x w x h mm)
Weight: approx. 2.3 kg
Display: LED display
Input voltage: 230 V 50 Hz / 2 A
(V = Volt, Hz = Hertz,
cycles per second)
Output voltage / 6 V / 10 A, 12 V / 10 A,
Output current: 24 V / 6 A DC (A =
ampere, DC = direct current)
Efficiency: > 80 %
Battery types: 6 V / 12 V / 24 V
Lead acid batteries:
▪ Lead acid storage
batteries
▪ Lead gel storage batteries
▪ Mat / AGM storage
batteries
▪ VRLA storage batteries
▪ Maintenance free lead
acid storage batteries
Battery capacity: 1.2 - 225 Ah
(ampere-hours)
Operating 0 C - 50 C (Celsius)
temperature:
Charging curve:
IOIUOUOIUOa
IP Class IP65, waterproof
(safety class):
Devices with Protective
Class II protective insulation
This equipment complies
with EU directives
▪ Low Voltage
Directive (2006/95/EC)
▪ Electromagnetic
compatibility directive
(2004/108/EC)
6.0 TECHNICAL
SPECIFICATIONS
5.1.4 Never expose charger to extreme
temperature fluctuations! Condensation can
damage the electronic circuit!
5.1.3 Always store charger in a dry location!
Moisture could damage the charger
' s electronic
circuit!
5.1.2 Clean the charger with a dry cloth.
Do not use liquids or harsh cleaning agents as
this may result in discoloration or damage to
the equipment surface, potentially damaging
the charger! Prevent any fluids from entering the
equipment! Never immerse the equipment in
fluids! Only operate charger when dry.
5.1.1 Caution! Power off charger (button )
and disconnect from 230 V alternating current
before cleaning the equipment!
5.1 Cleaning, maintenance and storage
5.0 MAINTENANCE
AND CARE
6
0
5
25
75
95
100
