Figure 2
C. The segments are turning. Automatic battery
detection may take up to 5 minutes.
B. Charger is ready for use. The two bars
in the display will flash.
A.
Positive / negative symbol will flash.
Incorrect battery clamp polarity.
3.4 What are the various LED display
symbols?
Battery charge indicator
Error message, incorrect battery clamp
polarity
Unit % (percent) indicating battery charge
level achieved
Left segment display
Right segment display
Unit V (Volt)
3.3 LED display and symbols
Left compartment with battery clamp
fixture
Handle
Storage shelf at the back of the equipment
for power cable and terminal cable.
Right compartment with battery clamp
fixture
Power cable with power plug
“Emergency Mode” button to manually
start and interrupt the charging process
LED Display
3.2 Product overview
9
3
4
2
1
5
6
7
Figure 1
0
5
25
75
95
100
