06 Starting and driving
Towing
06
140
Emergency towing
A
B
C
G028091
Front towing eyelet
The towing eyelet is located in the tool bag,
under the floor of the trunk, with the spare tire.
This eyelet must be screwed into the positions
provided on the right sides of either the front or
rear bumper (B, see illustrations).
WARNING
Do not use the towing eyelets to pull the
vehicle up onto a flat bed tow truck.
To attach the towing eyelet:
A. Use a coin to pry open the lower edge of
the cover (A) 1 .
B. Screw the towing eyelet (C) in place, first
by hand and then using the tire iron until it
is securely in place.
After the vehicle has been towed, the eyelet
should be removed and returned to the tool
bag. Press the cover back into position.
A
B
C
G028093
Rear towing eyelet
Precautions when the vehicle is in tow
• The steering wheel must be unlocked. Turn
the ignition key to position I or II.
• The gear selector must be in position N.
• Maximum speed: 50 mph (80 km/h). Do not
exceed the maximum allowable towing
speed.
• Maximum distance with front wheels on
ground: 50 miles (80 km).
• While the vehicle is being towed, try to
keep the tow rope taut at all times.
• The vehicle should only be towed in for-
ward direction.
1 The opening in the cover may vary.
