09 Maintenance and servicing
Battery 09
196
Corrosive
No smoking, no open flames,
no sparks
Explosion
Replacing the battery
G028419
Ventilation hose
1. Switch off the ignition and remove the key.
2. Wait at least 5 minutes after switching off
the ignition before disconnecting the bat-
tery so that all information in the vehicle's
electrical system can be stored in the con-
trol modules.
3. Remove the bolts on the retaining bracket
over the battery and lift out the bracket.
4. Fold up the plastic cover over the negative
(ground) battery terminal. or unscrew the
cover over the battery.
5. Disconnect the negative cable.
6. Lift off the plastic cover if necessary and
disconnect the positive cable
7. Pull the ventilation hose from the battery.
8. Lift out the old battery.
Installing a new battery
1. Put a new battery into place.
2. Put the lower retaining bracket in place and
retighten the bolt.
3. Reconnect the positive cable.
4. Press the cover for the positive battery ter-
minal into place and fold down the lid of the
plastic cover.
5. Connect the negative (ground) cable and
fold down the plastic cover if applicable.
6. Be sure that the ventilation hose is securely
connected to the battery and that the other
end of the hose is properly routed through
the ventilation opening in the floor of the
battery compartment (see the illustration).
7. Reinstall the retaining bracket over the bat-
tery and retighten the nuts.
