11 Specifications
Electrical system
11
244
General information
12-volt system with voltage controlled gener-
ator. Single wire system in which the chassis
and engine block are used as conductors,
grounded on the chassis.
Battery
Voltage: 12 V
Voltage 12 V
Cold start capacity
(CCA)
600 A
Reserve capacity
(RC)
120 min
Capacity (Ah) 70
If the battery must be replaced, replace it with
one with the same cold start capacity and
reserve capacity as the original (see the decal
on the battery).
WARNING
The distributor ignition system operates at
very high voltages. Special safety precau-
tions must be followed to prevent injury.
Always turn the ignition off when:
Replacing distributor ignition components
e.g. plugs, coil, etc.
Do not touch any part of the distributor igni-
tion system while the engine is running. This
may result in unintended movements and
body injury.
WARNING
PROPOSITION 65 WARNING!
Battery posts, terminals, and related acces-
sories contain lead and lead compounds,
chemicals known to the state of California
to cause cancer and reproductive harm.
Wash hands after handling.
Generator
Max. current: 140 A
Starter motor
Power: 1.4 kW
Spark plugs
P/N272313-8 or equivalent
Gap: 0.028 – 0.032 in. (0.7 – 0.8 mm)
Tightening torque: 22 ft. lbs. (30 Nm)
Firing order: 1-2-4-5-3.
