IR Remote Control
I
Menu
F1
F4
F2
F5
F3
F6
I
Menu
F1
F4
F2
F5
F3
F6
Reserved To the right Channel 5
Reserved Channel 1 Channel 6
Reserved Channel 2 Channel 7
Reserved Channel 3 Channel 8
0x08 0x53 0x57 0x30 0x08
0xff 0x04
0xed 0xaa
0x03
0xff
0x02
Read Machine Number
0x08: Command Length
0x53 0x57 0x30 0x08: Check Code
0xff :Machine number
0x04: Command ID
0xed: Check sum
Ack
0xaa: Header
0x03: Command length
0xff: Machine Number
0x02: Check Sum
