SPECIFICATIONS:
Model Name
AT-3GSDI500
Technical
Role of usage
Pattern generator
SDI standards
3G / HD / SD-SDI
Auto SDI rate detection
Yes
Supported protocols
SMPTE 259M (270Mbps / 360Mpbs)
SMPTE 292M / HDTV (1.485 & 1.485/1.001Gbps)
SMPTE 424M / 425M (2.97 & 2.97/1.001Gbps)
Video bandwidth
2.97Gpbs
Data rates
143 / 270 / 1483 / 1485 / 2967 / 2970 Mbps
Video support
[3G] 1080p@50/59.94/60 (4:2:2)
[HD] 720p50/59.94/60, 1080p24/30, 1080i50/59.94/60
[SD] [email protected], PAL@50Hz
SDI signal type
SMPTE-292M / 259M / 424M
Pathological pattern (RP-198)
Immune
HDMI
TH
bypass
Yes
Output impedance
75Ω
Cable (Belden 1694A)
equalization / transmission
3G-SDI - up to 190ft (60m)
HD-SDI - up to 500ft (150m)
SD-SDI - up to 1000ft (300m)
Audio support
Yes
PCB Stack-up
4-layer board [impedance control — differential 100Ω; single 50Ω]
Input
None
Output
2x BNC [SDI]
BNC connector
75Ω interlocking socket
HDMI
TH
connector
Type A [19-pin female]
[HD] Eye pattern characteristics
Amplitude: Within 800mV <10%
Rise overshoot: Less than 2%
Fall overshoot: Less than 2%
Long time jitter <1.0 UI
Timing jitter <1.0 UI
Alignment jitter <0.2 UI
Mechanical
Housing
Metal enclosure
Dimensions
[L x W x H]
Model
6” x 4.7” x 1.3” (154 x 119 x 33mm)
Package
7.7” x 12.8” x 3.6” (196 x 325 x 92mm)
Weight
Model
1.4 lbs (633g)
Package
2.8 lbs (1260g)
Fixedness
Latch-locking power supply
Power supply
5V 4A DC
Power consumption
10 Watts [max]
Operation temperature
32~104°F (0~40°C)
Storage temperature
-4~140°F (-20~60°C)
Relative humidity
20~90% RH [no condensation]
The measurement results are from Tektronix WFM-7120 with SDI through 3.3ft (1m) long Belden 1694A.
