9
www.atlona.com | toll free: 1-877-536-3976
For International: 1-408-962-0515
6.3. Output Panel
3 4 5
3. SDI OUTPUT A: Connect to a SDI device for SDI, HD-SDI, or 3G-SDI signal output either from the chosen
pattern or the converted HDMI TH source signal
4. Lock LED: showing if the audio/video signal existed or not
5. SDI OUTPUT B: Connect to a SDI device for SDI, HD-SDI, 3G-SDI signal output either from the chosen
pattern or the converted HDMI TH source signal
6.4. Bottom Panel
A 4-pin DIP switch is used for user interface, and users can access this switch from the bottom of the unit.
Pin No. 1 2 3 4
ON ( ↑ )
Used for SMPTE352M
3G level B 10 Update EDID
OFF ( ↓ ) 3G level A Not in use Default EDID
1. Factory default for 4-pin DIP switch: OFF-OFF-OFF-OFF [ ↓ - ↓ - ↓ - ↓ ]
2. In order to keep the compatibility of HDMI TH to most monitors, AT-3GSDI500 features EDID learning ability.
The operation is shown in the EDID LEARNING section.
EDID LEARNING:
1. Power off AT-3GSDI500 and set the pin 4 of DIP switch of AT-3GSDI500 to OFF [ ↓ ].
2. Connect the HDTV to the HDMI TH port on the AT-3GSDI500, and then power on AT-3GSDI500.
3. The Lock LED on the AT-3GSDI500 will dim and light again, which indicates the EDID learning process is
done.
4. Connect AT-3GSDI500 to the HDMI TH source through a HDMI TH cable and enjoy the experience.
