FUNCTION MENU:
5.1. Format
● Resolution – NTSC / PAL / 720p / 1080p / 1080i
● Frequency – 60Hz / 59.94Hz / 50Hz / 30Hz / 29.97Hz / 25Hz / 24Hz / 23.98Hz
● Output – YCbCr 4:2:2
5.2. Video
● Patterns – SMPTE Bar / 100% Bar / Check Field / EQ / PLL
Gradient R1 / Gradient G1 / Gradient B1
Gradient R2 / Gradient G2 / Gradient B2
Gradient R3 / Gradient G3 / Gradient B3
Gradient R4 / Gradient G4 / Gradient B4
Red Level 1 / Red Level 2
Green Level 1 / Green Level 2
Blue Level 1 / Blue Level 2
100% Red / 100% Green / 100% Blue / White / Gray Level
40% Gray / 70% Gray / Black / Noise
Circle 1 / Circle 2 / Moire
H Stripe R / H Stripe G / H Stripe B
V Stripe R / V Stripe G / V Stripe B
Chess 1 / Chess 2 / Sequence
● Text – Off / On-White / On-Black
● Timer – Off / On-W/B / On-B/W
5.3. Audio
● Mode – Off / On
● Group – 1+2 / 3+4
● Level – -6dB / -12dB / -18dB / -24dB / -30dB / -36dB / -42dB / Silence / Random
● Mask – Off / CH 1234 / CH 1 / CH 2 / CH 3 / CH 4 / CH 1+2 / CH 3+4
5.4. Motion
● Motion – No Motion / Square 1 / Square 2 / 2 Squares / Square Inv
● Data Speed – 1 / 2 / 3 / 4 / 5 / 6 / 7 / 8
5.5. ANC Data
● SMPTE-352M – Off / On
● EDH – On / Off
5.6. System
● Status – No Change / Factory / Now Save
● Version – V1.01
