BIXOLON SPP-R200II - Manual (Page 30)

Rev. 1.03 - 30 -
SPP-R200II
9. Appendix
9-1 Specifications
Item Description
Printing
Printing Method Thermal printing
Printing Speed 90 mm/sec (Receipt Paper), 80 mm/sec (Linerless Paper)
Resolution 203 DPI
Paper Supply
Mode
Easy paper loading
Character Size Font A: 12 × 24 Font B: 9 × 17 Font C: 9 × 24
Characters
Per Line
Font A: 32 Font B/C: 42
Character Set
English: 95
Expanded Graphics: 128 × 33 pages
International: 32
Barcode
1 Dimension: UPC A, UPC E, CODE 39, CODE 93, Code
128, EAN 8, EAN 13, ITF, Codabar
2 Dimension: PDF417, DATAMATRIX, MAXI, QR Code
Emulation BXL/POS
Driver
Windows XP(32/64bit) / WEPOS / 2003 Server(32/64bit) /
VISTA(32/64bit) / 2008 Server(32/64bit) / 7(32/64bit) /
8(32/64bit)
SDK
Windows XP / WEPOS / 2003 Server /
VISTA / 2008 Server / 7 / 8 / CE 3.0 and later
Sensor Paper End, Paper Cover Open
Cutter Type Tear-Bar
Language User language supported
Paper
Paper Shape Receipt Linerless
Paper Type Thermal Paper Thermal Paper
Outer Diameter of
Paper Roll
Max. ø40 mm (1.57”) Max. ø39 mm (1.54”)
Width 57.5 ± 0.5 mm (2.26” ± 0.2”) 57.5 ± 0.5 mm (2.26” ± 0.2”)
Thickness 0.07 ± 0.003 mm 0.08 ± 0.008mm
Reliability
Printer 50 km (Receipt Paper), 10 km (Linerless Paper)
Battery Rechargeable up to 500 times
Communications Interface
Serial/USB, Bluetooth Class2 V3.0 + EDR
Wireless Lan 802.11 b/g
* Communication is enabled only for devices with Bluetooth
or Wireless LAN function.
Battery
Charger
Input Voltage: 100 ~ 250 VAC Current: 0.5A (Max. at 110VA)
Output
Voltage: 8.4 VDC Current: 0.8A
* Charging current and charging time may depend on the
type (option) of the charger.
Battery
Type Lithium-ion
Output
Voltage: 7.4 VDC (Available 8.4 ~ 6.8VDC)
Capacity: 1200 mAh
Charging Time 2.5 hours
Usage
Conditions
Temperature
Printer: -15~50℃ (5~122℉)
Battery: 0~40℃ (32~104℉)
Battery discharge: -20~60℃ (-4~140℉)
Humidity
Printer: 10~80% RH (No condensation)
Battery: 20~70% RH(Non-condensing, refer to the tempera
ture conditions on page 8)
Dimensions Printer 79.5mm × 126.7mm × 43.6mm (3.13″ × 4.99″ × 1.72″)
Weight Printer
Printer : 197g (0.43lbs)
Printer + Battery : 250g (0.55lbs)
Printer + Battery + Paper : 307g (0.68lbs)
Package: approx. 1000g (2.2lbs)
Accessories
Basic Package Battery Pack, Battery Charger, Belt Strap, Paper
Sold Separately
Vehicle Holding Cradle, Belt Clip, Vehicle Charger,
Interface Cable, Single Battery Cradle, Shoulder Strap, Case,
Protective Case, Cleaning Pen, Battery Pack_V2(with outter
contacts), Single Docking Cradle, Quad Docking Cradle,
Quad Battery Charger, Wall Mount(for Quad Battery Charger)
* This equipment is indooruse and all the communication hiring are limited to inside of the building.
* The switch is the disconnecting device. Turn off switch from any hazard.
