Operation
Ilumipod Inground IP Series User Manual (Rev. 4) 15
DMX Values
ARC 1
Channel Function Value Percent/Setting
1 Red 000 ó 255 0 ~ 100%
2 Green 000 ó 255 0 ~ 100%
3 Blue 000 ó 255 0 ~ 100%
ARC 1 + D
Channel Function Value Percent/Setting
1 Dimmer 000 ó 255 0 ~ 100%
2 Red 000 ó 255 0 ~ 100%
3 Green 000 ó 255 0 ~ 100%
4 Blue 000 ó 255 0 ~ 100%
ARC FULL
Channel Function Value Percent/Setting
1 Dimmer 000 ó 255 0 ~ 100%
2 Red 000 ó 255 0 ~ 100%
3 Green 000 ó 255 0 ~ 100%
4 Blue 000 ó 255 0 ~ 100%
5 Color Macro + White Balance
000 ó 010
011 ó 030
031 ó 050
051 ó 070
071 ó 090
091 ó 110
111 ó 130
131 ó 150
151 ó 170
171 ó 200
201 ó 205
206 ó 210
211 ó 215
216 ó 220
221 ó 225
226 ó 230
231 ó 235
236 ó 240
241 ó 245
246 ó 250
251 ó 255 No Function
Red 100%
Green Up Blue 0%
Red Down Green 100% Blue 0%
Red 0% Green 100% Blue Up
Red 0% Green Down Blue 100%
Red Up Green 0% Blue 100%
Red 100% Green 0% Blue Down
Red 100% Green Up Blue Up
Red Down Green Down Blue 100%
Red 100% Green 100% Blue 100%
White 1: 3,200 K
White 2: 3,400 K
White 3: 4,200 K
White 4: 4,900 K
White 5: 5,600 K
White 6: 5,900 K
White 7: 6,500 K
White 8: 7,200 K
White 9: 8,000 K
White 10: 8,500 K
White 11: 10,000 K
6 Strobe
000 ó 004
005 ó 255 No Function
0 ~ 20 Hz
7 Dimming Speed
000 ó 009
010 ó 029
030 ó 069
070 ó 129
130 ó 189
190 ó 255 Dimmer is set by Ilumicode
OFF (Dimmer is linear)
DIM1 (Fastest dimmer curve)
DIM2
DIM3
DIM4 (Slowest dimmer curve)
