Chapter 3 : FRONT PANEL DISPLAY MENU DESCRIPTION (continued)

OPTIMIZER HD

PAGE 18

3-5. FUNCTIONS DESCRIPTION (continued)



[CONTROL]



[Versions]

Status of the internal firmware.



[RS232/LAN]

Select the needed communication port.


[RS232]: Enables the RS-232 communication port. (Default setting).



[LAN]:

Enables the LAN communication port.

IMPORTANT: To avoid addresses conflict, configure the LAN communication port (with the LAN setup menu)

before activating it.

NOTE: The RS-232 & the LAN communication ports can not be used simultaneously.



[LAN setup] (Available with the LAN option only)

Allows configuring the LAN communication port. Select the UDP or TCP protocol then select the needed
parameters.


[device addr.]: Each device connected to an IP network must have a unique IP address. This address is used

to reference the specific unit. IP addresses are specified as w.x.y.z where each w, x, y, & z
are numbers from 1 to 254. Assign the device to a unique IP address. (Default value:
192.168.0.2).



[remote addr.]: This is the destination IP address used with an outgoing connection. Select the destination IP

address. (Default value: 192.168.0.1).



[gateway addr.]: The gateway address, or router, allows communication to other LAN segments. The gateway

address should be the IP address of the router connected to the same LAN segment as the
unit. Select the gateway address. (Default value: 192.168.0.1).



[device port]:

Every TCP connection and every UDP datagram is defined by a destination IP address and a
port number. Select a local port number between 10000 and 10999. (Default value: 10500).



[remote port]:

You must set the remote TCP port number for the unit to make outgoing connections. This
parameter defines the port number on the target host to which a connection is attempted.
Select a remote port number between 00000 and 655000. (Default value: 10500).



[netmask]:

A netmask defines the number of bits taken from the IP address that are assigned for the host
section. The device prompts for the number of host bits to be entered, then calculates the
netmask, which displays in standard decimal-dot notation when the saved parameters are
displayed. Select the netmask. (Default value: 255.255.255.0).



[default setup]: Set all the LAN settings to the default value.

MAC ADDRESS: The MAC address, also referred to hardware address, is a unique number assigned to each

device. The MAC address is available on the bottom device label.



[Key locking]

Select an item between:


[All]:

Locks/unlocks all the front panel switches.



[Menus]: Locks/unlocks the CONTROL switches.

NOTE: To unlock presses simultaneously on ENTER and EXIT.



[Stand-by]



[On]: Manual activation of the Stand-by mode.



[Auto After]: Select the condition to automatically switch the machine into the standby mode.



[Sync loss]: The standby mode is automatically activated when the sync. of the selected input is not

anymore detected.


[Stand-by time]: The standby mode is activated after the duration of your choice.



[Sync loss + time]: The standby mode is activated when the sync. of the selected input is not anymore

detected and after the duration of your choice.



[Erase memories] + ENTER.

This function allows erasing all the image position setting memorized.



[Default value] + ENTER.

This function allows clearing the following adjustments and setting them to the factory value
