INTRODUCTION TO TAHOMA MiniQ MULTIVIEWERS
The Apantac Tahoma MiniQ Multiviewer platform displays multiple auto-detecting video inputs
at different formats on a high resolution display up to resolutions of 1920x1200. The Tahoma
MiniQ Platform combines the display of video windows, audio meters, label/UMD, tallies, alarms
and indicators in a very space efficient package
5B
HARDWARE
The Apantac Tahoma MiniQ Multiviewer Platform consists of the following
4 different sizes of mechanical frames to serve the needs of broadcast, professional AV and
surveillance markets. These frames are ½ width of 1 RU, 1 RU, RU and 3RU. Each Multiviewer
frame has a unique IP address, which allows a PC/laptop to easily connect and configure the
display layouts.
1. MiniQ Module-> A quad video processor that allows 4 video inputs from CV, SD/HD-SDI
to 3G SDI
2. MiniQ-3U-FR -> 3 rack unit frame that can house up to 8 MiniQ modules, comes with 2
MiniQ-3U-PS (hot swappable power supplies)
3. MiniQ-1U-FR -> 1 rack unit mounting plate that can provide rack mount for up to 3
MiniQ modules
4. MiniQ-1U-PS -> External DC power supply for single MiniQ module
