FRU Information and Sensor Data Records
AXP 1410 Installation and Use (6806800H70L)
147
7.2.2
Fan Tray Module Analog Sensors
The analog sensors available on the FTM can be divided into the following three categories:
7.2.2.1
Voltage Sensors
The following sensors measure voltages of the FTM.
31
FTM Temp 2
Temperature
Fan Tray Module
Temperature Sensor 2
Threshold
Always
32
FTM Temp 3
Temperature
Fan Tray Module
Temperature Sensor 3
Threshold
Always
33
FTM Temp 4
Temperature
Fan Tray Module
Temperature Sensor 4
Threshold
Always
34
FTM Temp 5
Temperature
Fan Tray Module
Temperature Sensor 5
Threshold
Always
Table 7-1 IPMI Sensors on the Fan Tray Module (continued)
Sensor
No.
Sensor Name
Type of
Measurement
What does it measure?
Sensor Type Availability
Table 7-2 Sensor No. 3 +12V A_MON
Feature
Raw Value/Description
Interpreted Value
Sensor Name
+12V A_MON
Device
Sensor Type
0x02
Voltage
Class
0x01
Threshold
Sensor Owner LUN
0x00
Entity ID
0x0A
Power Supply
Entity Instance
0x60
