Shelf Management Alarm Module
AXP 1410 Installation and Use (6806800H70L)
196
8.6
Ethernet Connector (Out-of-Band)
One 10/100 Mbps Ethernet port is provided via the Ethernet connector on at the face plate. It
allows external system managers to access the shelf manager.
Blue (H/S)
Blue
Blue (steady): The shelf manager board is ready to be extracted.
Blue (long blink): The board has been inserted or powered on and
is beginning the integration process. The eject handle switch is
closed.
Blue (short blink): The eject handle switch is open or an
extraction has been requested. The board is shutting down and
transferring control of the shelf to the other shelf manager board.
Off: The shelf manager board is not ready to be extracted. Do not
remove the board during this state.
In Service (I/S) LED
Green
Green: The shelf manager board is working properly.
Off: The shelf manager is not working properly or is initializing
after power-up.
OOB Activity
Green
Amber: Activity
Off: No activity
OOB Linkup
Amber
Green: Link to Ethernet 3 is available.
Off: Otherwise
Table 8-2 Face Plate LEDs (continued)
LED
Color
Description
