CommLink IV Technical Guide
7 Operator Interface
USB Driver Installation for Windows
®
XP
5. The next window that appears will ask, “What do you want
the wizard to do?” Select “Install from a list or specifi c loca-
tion (Advanced)” as shown below and click
<Next> .
6. In the next window that appears, select the radio
button in front of the option “Search for the best driver
in these locations.” Uncheck the box that reads, “Search
removable media” and instead check the box “Include this
location in the search:”
7. Click <Browse> and locate the drive that your
CD-ROM is located on. Click <Next> .
USB Serial Converter Driver
Installation for Windows
®
XP
CAUTION: You must use the drivers on the CD-ROM supplied
with the CommLink IV. DO NOT download
drivers from the FTDI website, because they will
not work for the CommLink IV Interface!
NOTE: If for any reason you cancel out of the New Hardware
Wizard before installing the USB drivers or if you
receive an error message during installation, the driv-
ers will not be installed. You must then install the
drivers using the directions in the XP Troubleshooting
Section on page 17.
1. Plug the USB cable attached to your CommLink into your
computer’s USB port.
2. Insert the USB Drivers CD-ROM into your CD-ROM
drive.
3. A message should pop up from the toolbar that reads,
“Found New Hardware.” Click on the Found New
Hardware Wizard application from the toolbar.
4. The window that appears will ask the question, “Can
Windows connect to Windows Update to search for soft-
ware?” as shown below. Select “No, not this time”
and click
<Next> .
