Setting-Up the AX4020
________________________________________________________________
6
Installation Guide - AX4020 Office Server
3 - SETTING-UP THE AX4020
This chapter describes the set-up procedure for the AX4020.
Note: for more information, refer to the guide: AX4000 - User's Manual.
The AX4020 provides an embedded interactive set-up. This interactive set-up
allows the network environment (IP address, host table, etc.), the serial line
parameters (data transfer rate, handshake, etc.), and the network services
associated with the serial lines (telnet, lpd, etc.), to be set.
The AX4020 set-up can be entered from:
- a serial character terminal connected to the AX4020 Ch8 port,
- a telnet session launched from any network point.
3.1 - FROM A SERIAL CHARACTER TERMINAL
Plug a character terminal into the AX4020 Ch8 port and set up this terminal in
the following way:
- data transfer rate: 9600 bps
- data: 8 bits
- stop bit: 1
- parity: none
- handshake: none
- keyboard: ASCII mode
Note: any emulation or personality can be used.
An administrator switch is located on the AX4020 rear panel. Press this switch
to enable set-up mode.
The set-up main menu is displayed on the character terminal.
When the set-up session has been completed, the Ch8 port can be used for
other network services.
