13
3 While holding thread with fingers, pass it
between the tension discs and pull thread
down to make certain it is properly located in
between the tension discs.
4 &
5
Slip thread behind metal guide and
into center slot on thread guide.
6
Pass thread into the slot of take-up lever
cover.
7
Position thread into the center slot on guide
located at base of take-up lever cover.
8 Slip thread from left to right into the thread
guide located on bottom of the needle
clamp. Position the thread into the center
section of the guide.
Note: For 4-Thread overlock left needle: Use
Needle A.
Note: Before threading eye of needle, slip
thread behind thread guide located on the
bottom of the needle clamp.
Note:
For Chain stitch: Use needle D before
threading eye of needle, make sure thread is
in front of thread guide located at bottom of
the needle clamp.
9 Thread the eye of the center needle from
front to back. Position of the thread must
be behind the thread guide for overlock
stitching. Draw about 10cm (4 inches) of
thread through needle eye toward the rear
of machine and place thread to the back,
under the presser foot.
Note: Use tweezers provided in the
accessory case to aid in threading
the needle.
