Electrical connection
YOUR COOKER IS INTENDED FOR FITTED AND
PERMANENT INSTALLATION.
o
Before connecting the appliance, make sure that the supply
voltage marked on the rating plate corresponds with your mains
supply voltage.
o
We recommend that the appliance is connected by a qualified
electrician, who is a member of the N.I.C.E.I.C. and who will
comply with the I.E.E. and local regulations.
o
WARNING: THIS APPLIANCE MUST BE EARTHED.
o
This appliance is supplied with a moulded plug, which must be
connected to an earthed socket.
o
If in future you need to change the fuse in this plug, then a 3
amp ASTA approved (BS 1362) fuse must be used.
o
If the earthed socket is not accessible after the appliance is
installed. Then the cooker must be wired into a 13 A double pole
switched fused spur outlet, having 3 mm contact separation and
the fuse rating reduced to 3 amps. This should be placed in an
easily accessible position adjacent to the appliance. The spur
outlet must still be accessible even when your cooker is installed.
o
The wiring in the mains lead is coloured as follows:
Brown
Live
Blue Neutral
Green and yellow Earth
o
As the colours of the wires in the appliance’s mains lead may not
correspond with the coloured markings identifying the terminals
in your spur box, please proceed as follows:
The brown wire must be connected to the terminal marked “L”
(live), or coloured red.
The blue wire must be connected to the terminal marked “N”
(neutral), or coloured black.
