o
Unscrew the injector and replace it with the required injector for
the new gas supply according to the table below.
Burner Type Gas Type Pressure
Mbar
Injector
Marking
(1/100mm)
Power
(Kw)
Max Min
Natural
Gas
20 1.05 Oven Burner
Liquid Gas 28..30/37 0.72
2.1 0.8
Natural
Gas
20 1.00 Grill Burner
Liquid Gas 28..30/37 0.66
1.8 0.6
o
After changing the injectors YOU MUST change the minimum
flow rate.
Minimum flow adjustment for the oven and grill burners
All work must be carried out by a GASSAFE
registered engineer.
o
In order to access the adjusting screws to change the minimum
flow rate of the grill and oven burners, you need to remove the
hob top and control panel.
o
To take the hob top off, remove the screws fixing the hob to the
cooker.
35
o
When all the screws have been removed, slide the hob from the
back to the front and lift it off the support brackets which hold
the hob down at the front of the cooker.
