12
Procedure
1. Place the cool unit with the glass ceramic plate down
on a flat surface.
2. Using a suitable crosshead screwdriver, undo the
six screws in the back panel.
3. Place the body so that the front ofthe glass ce-
ramic plate is lying on the flat surface.
4. Take the cool lamp by the left or right end and press
it carefully to the right or left.
5. Now lift it forwards and out of the socket.
Note
Use a cloth to hold the new lamp when inserting it,
not bare fingers, as the grease on your skin could
damage the coating on the lamp.
6. Insert the new lamp in the socket. The new lamp is
inserted in the reverse order to removal.
7. Close the unit again. The unit is closed in the reverse
order to opening it.
Make sure that no foreign objects are left in the
body of the unit and that nocables become trapped.
Storage
Remove the mains plug and let the unit cool down
completely before you move it.
If possible, store the infrared radiant heater in its origi-
nal packaging in a dry place.
7. Technical specifications
Mains connec-
tion AC 220 V – 240 V / 50 – 60 Hz
Power con-
sumption 300 W
Timer Adjustable from 1 to 15 minutes in
one-minute steps.
Dimensions
(WxHxD) 270 x 285 x 195 mm
Weight Approx. 1.6 kg
Operating
conditions
Temperature: 10 °C to 35 °C
(-14 °F to 95 °F)
Relative humidity: ≤ 90 %
Storage and
transport:
Temperature: -10 °C to 50 °C
(-50 °F to 122 °F)
Relative humidity: ≤ 90 %
Protection
class II
Radiation
intensity Max. 200 mW/sqm
IR type A + B
We retain the right to make technical modifications to
improve and further develop the product. For manufac-
turing reasons, the colour of the glass may change dur-
ing operation but this does not affect the performance
or quality of the unit.
8. Disposal
In the interests of environmental protection, the infrared
lamp should not be discarded with household rubbish
at the end of its service life. Dispose of the unit at a
suitable local collection or recycling point. Follow the
local regulations for disposal of materials.
Dispose of the unit in accordance with the EC
Directive for waste electrical and electronic
equipment 2002/96/EC – WEEE (Waste Elec-
trical and Electronic Equipment). If you have
any questions, please contactz the local authorities
responsible for waste disposal.
This equipment complies with European standard
EN 60601-1-2 and is subject to specific safety provi-
sions for electromagnetic compatibility. Please note,
however, that portable and mobile HF communication
equipment may influence this unit. More details can be
requested from the stated Customer Service address
or found at the end of the instructions for use.
