BrightSign HD2000
Overview
This hardware reference manual specifies the hardware interfaces on the HD2000, as well as providing a
guide to troubleshoot the hardware of the HD2000 for in-field service. This manual will not describe any
software functions.
The BrightSign HD2000 is a device that can be used to drive a variety of HDTV and computer monitors
for digital sign and kiosk applications. As well as driving the Video Display, the HD2000 has many
different control interfaces built in to allow the sign to be controlled. The Brightsign HD2000 is
differentiated from the HD2000 in that the HD2000 can decode MPEG2 HD video files and it has HDMI
output, as well as additional IO interfaces.
This information applies to a product under development. Its characteristics and specifications are subject to change without notice. Roku assumes no
obligation regarding future manufacturing unless otherwise agreed to in writing.
www.rokulabs.com © Roku 2006
