L-1884-C 27.
SPECIFICATIONS
Dimensions
Size (maximum tow weight) ..................................79 kg (175 lbs).
Capacity .........................................................0.10 cu m (3.5 cu ft).
Tires
Size ......................................................................................13 x 5
Inflation Pressure ................................................................. 20 psi
GETTING QUALITY SERVICE
Quality Continues with Quality Service
We provide a process to handle your questions or problems.
Follow the steps below to get answers to any questions you may have
about your product.
1. Refer to your attachment and machine operator manuals.
2. In North America or Canada, call 1-877 728-8224 and provide
product serial number (if available) and model number.
Table 2: Troubleshooting - Spreading Difficulties & Remedies
PROBLEM CAUSE/CONDTION REMEDY
Too much/not enough
material dispensed. Gage Plate not calibrated Insure Gage Plate is properly calibrated, (Refer to Figure 11).
Flow Control Handle
hard to operate or
won’t move Gate(47) and directional con-
trol plate(46) clogged with
material. Remove and clean the Gate and Directional Control Plate with
soap and water, (Refer to Figure 12 through Figure 15).
Fan does not turn
when towing
spreader. Drive hairpin cotter (22) not
properly inserted through
Wheel hub (9) hub and axle
(6.)
Transmission cotter pin (40)
missing or not properly
inserted through transmission
hub (21) hub and axle (6)
Fan (25) hits bottom of hopper
gate (47) and directional con-
trol plate (46).
Fan (25) slips on transmission
shaft (21).
Transmission malfunction
Install or replace missing hairpin cotter, (Refer to Figure 5)
Install or replace missing cotter pin through transmission hub
(21) hub and axle (6), (Refer to Figure 4).
Adjust fan to clear hopper gate and directional control plate,
(Refer to Figure 6).
Install Fan Driver (24) so that the four fan gussets on the bot-
tom of the fan compresses the fan driver.
With the broadcast spreader attached to your machine lift the
drive wheel and rotate. At the same time apply gentle pressure
to the fan shaft. It should turn with each rotation of the wheel.
TROUBLESHOOTING
