Figure 3.
ASSEMBLY FAN TO TRANSMISSION
24
Fan Driver
Qty. 1
3a. Slide the Fan Driver (24) and Fan (25)
on to the shaft of the Transmission
Assembly (21) until both reach the Pin
Spring (23)
Note: This is for pre-assembly only. Final
adjustment of the fan is made later.
24
23
25
21
