Hardware Installation
The Serial ATA connectors are used to connect Serial ATA devices. Connect one
end of the Serial ATA cable to a SATA connector and the other end to your Serial
ATA device.
SATA (Serial ATA) Connectors
7
RXN GND
TXP
TXN
GND
1
RXP
GND
SATA 3 SATA 2
SATA 0
SATA 1
