Repair Parts
D3858-US-Rev A
John Deere 750/1560/1590-20 ft Grain Drill
11
KEY
QTY.
PART NO.
DESCRIPTION
1
1
405874 Weld – Middle Support (JD750MB20)
2
1
405760 Weld – Rear Brkt LH (JD750-15’)
3
1
405761 Weld – Rear Brkt RH (JD750-15’)
4
1
405762 Weld – Front Brkt LH (JD750-15’)
5
1
405763 Weld – Front Brkt RH (JD750-15’)
6
2
405764 Weld – Middle Brkt (JD750-15’)
7
1
405851 Weld – Front Middle Supt (JD1590-20’)
8
1
405846 Weld – Rear Middle Supt (JD1590-20’)
9
1
405848 Plate-8 Hole Mnt Rear (JD1590-20’)
10 1
405847 Angle-4 Hole x 6” (JD1590-20’)
11 10
405854 Scr 1/2-13 x 2-1/4 HHCS ZP Grd 5
12 2
405864 Scr 5/8-11 x 2-1/2 HHCS ZP Grd 5
13 12
405863 Scr 5/8-11 x 8-1/2 HHCS ZP Grd 5
14 2
405866 Scr 5/8-11 x 10 HHCS ZP Grd 5
15 12
171610 Wash 3/8 Flat Narrow ZP
16 10
405053 Wash 1/2 Flat Wide ZP
17 28
405858 Wash 5/8 Flat Wide ZP
18 10
406085 Nut 1/2-13 Ser Flange ZP
19 16
406070 Nut 5/8-11 Top-Lock Flange ZP
20 12
405859 Pin-Cotter 5/32 x 1.5 ZP
21 6
405860 Pin-Clevis 3/8 x 2.25 ZP
22 6
405861 Pin-Clevis 3/8 x 2.5 ZP
23 6
405862 Link-Offset #40
24 2
405865 Spacer-1.5 (JD1590-20’)
25 1
405878 Paint-JD Green Aerosol
26 2
400373 Cell-1.5 DB-11FT
27 4
400400 Cell-1.5 DB-16FT
28 1
406233 Assy J-Box 6PT (Planter)
29 1
141837 Cable-30FT J-Box
30 1
406072 Cable-Power 6FT 2-Wire
31 1
405612 GT400 Indicator
