Pub. 42004-642L2E
Model 711-102 and 7115-102 Desk-Edge Subsets
Page 9 of 9
f:\standard ioms - current release\42004 instr. manuals\42004-642l2e.doc
04/13
Specifications
Construction/finish ..................................................... 16-gauge cold-rolled steel/gray polyurethane enamel
Handset microphone .............................................................................. Dynamic, noise-canceling, 10-ohm
Receiver ....................................................................... Dynamic, 150-ohm, hearing aid compatible
Cable ............................................................................................... PVC retractile, 6-foot extended
Material
............................................................................................................................ Gray ABS
External controls ............................................................................................... Handset pressbar for paging
rotary selector switch (Model 7115-102 only)
Mounting ........................................................................................................ Desk-edge or similar location;
Two 13/64-inch mounting holes (in bracket)
Temperature range ................................................................................ −22
F to 158 F (−30 C to +70 C)
Connections...................................................................... 8-foot cable with connector, hard-wired to subset
Dimensions .................................................... 7.38 H
3.12 W 4.00 D inches (187.4 79.2 101.6 mm)
Shipping weight ............ Single or multi-party .................................................... 3.6 lbs. (1.63 kg) maximum
Approvals
NRTL certified for use in US and Canada for ......................................... Class 1, Div. 2, Groups A, B, C, D
when connected to a certified Model 7245 Enclosure using a certified Model 723 Amplifier
Temperature Code ..................................................................................... T3C (Maximum ambient = 70º C)
CE Mark
Replacement Parts
Model No.
Description
10112-101
Handset Assembly with PVC Cord, 6 foot
12502-101 Replacement
Receiver
13204-002 Receiver
Cap
12511-001
Transmitter Dynamic Microphone & Cap
12512-011
Hookswitch Assembly Replacement Kit
12607-002
Party Line Selector Switch Kit
69200-101 Subset
Termination
PCBA
