- 17 -
Paper Jam Removal
Paper Jam Removal
The paper jam that is occurred in the Officemate 4D can be removed very easily.
The machine is stopped automatically when the paper jam is occurred. And the paper jam
can be removed by using the jam removal tool.
The machine starts to operating when the [Start/Stop] button is pressed after removing the
jam.
[Remove the 1 st CST] [Open the top cover by un-locking the
locking knob.]
[Remove the jam by using the jam removal tool]
! CAUTION : Please keep the jam removal tool to right position after removing the jam.
[Insert the tool into the hole on the press
roller and rotate the press roller by hand]
