80
3 Mounting the mecablitz
3.1 Mounting the mecablitz on the camera
Switch off camera and mecablitz with the main switch!
mecablitz 36 AF-5 C, 36 AF-5 N and 36 AF-5 P
• Turn the knurled nut against the mecablitz housing until the
stop point is reached.
• Slide the mecablitz foot completely into the camera’s acces-
sory shoe.
• Turn the knurled nut against the camera body as far as
possible, thereby clamping the mecablitz.
mecablitz 36 AF-5 S
• Push the mecablitz with the connection foot as far as it will
go into the camera accessory shoe. The safety catch can
be heard to snap into place on the hot shoe.
• Lightly press the unlatching button “PUSH” upward to
clamp the mecablitz in the camera’s accessory shoe.
☞
mecablitz 36 AF-5 O
• Push the mecablitz with the connection foot as far as it will
go into the camera accessory shoe. Then press the “LOCK
button” to secure.
3.2 Removing the mecablitz from the camera
Turn off the camera and the mecablitz by their main switch.
mecablitz 36 AF-5 C, 36 AF-5 N and 36 AF-5 P
• Turn the knurled nut against the mecablitz housing until the
stop point is reached.
• Withdraw the mecablitz from the camera’s accessory shoe.
mecablitz 36 AF-5 S
• Press the unlatching button “PUSH” towards the flash unit
and at the same time hold it lightly down until the “PUSH”
button locks in place.
• Withdraw the mecablitz from the camera’s accessory shoe.
☞
