6 7
3.5mm Input
This allows you to directly connect any source you choose
with a stereo 3.5mm stereo jack. (A music player. A laptop
or desktop etc.) The source will be heard from any Monster®
Soundstage™ speaker system(s) you choose.
Next Track Button
When touched and released, source will go to the
next track.
Previous Track Button
When touched and released, source will go back
one track.
Play/Pause/Mute Button
When touched and released, source device will be
paused (muted). When touched and released again,
playback will resume.
Volume Buttons
You can adjust the volume continuously by pressing
and holding the + or – button. You can adjust the
volume in small increments by pressing and releasing
the + or – button.
Monster ® SoundStage
™
Features and Controls Overview
Dieline Blade Speaker Small
Units: mm Scale: 1:1
Date: 05/23/2014
Version 6
1 3 2 4
6 7
5
8 9 10
Source Indicators
There are 4 Input Indicators. Two on the top right. Two on
the top left. The active input will run blue continuously.
Inactive inputs will not be illuminated.
WiFi Input
Bluetooth Wireless Input
Digital Input (Toslink Optical)
Analog Input (3.5mm)
Source Select Button
Choose from four input sources: WiFi, Bluetooth wireless,
Digital In, or Analog In.
The WiFi input is the default input. If none of the other
input options are selected, you will hear the WiFi
selection. Also, if you have chosen any of the other
inputs, and there is no signal for three minutes, the
device will automatically return to the WiFi default
input (see Input Set Up for more information).
1
2
3
4
5
6
7
8
9 10
4) Control
You can control your Monster® Soundstage™ using the
buttons and LED’s on the Monster® Soundstage™ itself.
Or you can control it from your Monster® Soundstage™ App
which offers extra features like grouping speakers and more.
Dieline Blade Speaker Small
Units: mm Scale: 1:1
Date: 05/23/2014
Version 6
Toslink Optical Digital
If you have source devices that provide a digital output,
Monster® Soundstage™ has an input for that.
Dieline Blade Speaker Small
Units: mm Scale: 1:1
Date: 05/23/2014
Version 6
Dieline Blade Speaker Medium
Units: mm Scale: 1:1
Date: 05/23/2014
Version 6
Dieline Blade Speaker Small
Units: mm Scale: 1:1
Date: 05/23/2014
Version 6
Dieline Blade Speaker Medium
Units: mm Scale: 1:1
Date: 05/23/2014
Version 6
