2
About your new Transom Boat
Thank you for deciding to buy a new Sea Eagle Tran som Boat. You
will get many years of use and plea sure out of this boat.
The Transom Boats have several unique fea tures which make them
solid, reliable boats. Transom Boats are made of 1000 Denier
Polyester - PVC inflatable hulls with at tached transom and the mold ed
polyethylene or High Pressure Drop Stitch floor system. Below is a
brief over view of the struc ture of the boat. Detailed assembly
instructions are on the following pages.
Packing List
We recommend checking your order as soon as you receive it to be
sure that all items are included.
14 SR
Box 1:
14 SR Boat Hull packed in Boat Bag with 12' Docking Rope, Repair
kit (contains valve adapter, patches, glue, Recessed Valve Adapter
tool, 2 eye bolts).
Box 2:
FB-1, FB-2, FB-3 (S), FB-3, & FB-4,
2 pcs. STR14L Stringer (124 cm/49")
2 pcs. STR14S Stringer (80 cm/31.5")
2 pcs. Uplift Connector Bars
3 pcs. Reinforcement kit for FB-2 & FB-4
WS2505 Aluminum Bench Seat
Bow Storage Bag,
A-41 High Pressure Foot Pump, AB25-5 Oars,
Instructions.
12.6 SR
Box 1:
12.6 SR Boat Hull packed in Boat Bag with 12' Docking Rope,
Repair Kit (contains valve adapter, patches, glue, Recessed Valve
Adapter tool).
Box 2:
FB-1, FB-2, FB-3, FB-4 Floorboards
2 pcs. STR124 Stringer (124 cm./49")
2 pcs. STR37 Stringer (37 cm/14.5")
2 pcs. Uplift Connector Bars
WS2505 Aluminum Bench Seat
Bow Storage Bag, A-41 High Pressure Foot Pump,
AB25-5 Oars, Instructions.
10.6 SR
Box 1:
10.6 SR Boat Hull packed in Boat Bag with 12' Docking Rope,
Repair Kit (contains valve adapter, patches, glue, Recessed Valve
Adapter tool).
Box 2 (Polyethylene Floorboard option):
FB-1, FB-2, FB-3(S), FB-4 Floorboards
2 pcs. STR80 Stringer (80 cm/31.5")
2 pcs. STR45 Stringer (45 cm/17.71")
2 pcs. Uplift Connector Bars
WS2505 Aluminum Bench Seat
Bow Storage Bag.A-41 High Pressure Foot Pump,
AB25-5 Oars,Instructions.
10.6 SR-RIK
Box 1:
10.6 SR Boat Hull packed in Boat Bag with 12' Docking Rope,
Repair Kit (contains valve adapter, patches, glue, Recessed Valve
Adapter tool).
Box 2 (Drop Stitch Floor Option):
Drop Stitch Floor
WS2505 Aluminum Bench Seat
Bow Storage Bag, A-50 High Pressure Foot Pump,
AB25-5 Oars, Instructions.
9.2 SR
Box 1:
9.2 SR Boat Hull packed in Boat Bag with 12’ Docking rope,
Repair Kit (contains valve adapter, patches, glue, Recessed Valve
Adapter tool).
Box 2:
FB-1, FB-2, FB-4 Floorboards
2 pcs. STR80 Stringer (80 cm/31.5")
2 pcs. Uplift Connector Bars
WS2505 Aluminum Bench Seat
Bow Storage Bag,A-41 High Pressure Foot Pump,
AB25-5 Oars, Instructions.
8.10 YT
Box 1:
8.10 YT Boat Hull in Boat Bag, Repair Kit (contains valve adapter,
patches, glue, Recessed Valve Adapter) & 12' Docking Rope.
High Pressure Drop Stitch Inflatable floor, AB25-5 Oars.
Box 2:
WS2505Aluminum Seat,
A-50 High Pressure Foot Pump, Instructions.
Recessed One-Way Valves on all chambers
The valve cap unscrews to reveal the valve stem. When this stem is
in the up position as shown the valve retains air. The valve
should be in this position to inflate the boat.
Use the recessed One-Way Valve Adapter
included with your boat to inflate this valve.
The adapter fits into the hose of any of our
pumps.
Push the adapter into the valve and turn
clockwise to lock it in position.
To deflate the air chamber, push the valve stem in
with your thumb and turn clockwise to secure it in
the down position. This will let the air out of your
boat.
