6
4.3 General precautions for locating the SKIPPER LT and cable runs
Positioning the SKIPPER LT device in the cab:
- DO NOT place the navigator in areas subject to excessive vibrations and shocks or
close to moving parts which might cause damages;
- Mount the remote control unit in a visible position, without obstructing the opera-
tor’s view, and within easy reach by hand;
- Take care to position the device away from moving parts to avoid accidental opera-
tion of its keys.
Inserting the connectors:
- Fit supplied O-rings into connectors and then connect paying special attention to
the notch. Press gently and then tighten the ring nut.
CAUTION: do not use tools to tighten down the connector locking collars.
- Do not force the connectors by pushing too hard or bending them: the contacts
can be damaged and monitor operation compromised.
Securing the cables:
- Note the various connections required for the SKIPPER LT system to operate, the
necessary length of the cables, and ensure that there is sufficient space for the cable
runs and connectors:
- Route the cables in such a way that twisting and machine movements cannot da-
mage or break them;
- Route the cables in such a way that they cannot come into contact with moving
parts;
- If, due to limited space, the cabling has to run around a corner, make sure that the
bend is not too sharp as this may cause the cable to break.
Use ONLY the cables and accessories listed in the catalogue; these have the correct
specifications for their intended application.
