LDK 4410 + LDK 5420 3G Fiber Transmission System User’s Guide (v1.0) 69
Chapter 6 - Connectors
☞
Note
☞
Note
Make sure that the applied external video inputs match the temporal frequency (50 or
59.94 Hz) of the selected camera video mode and that they are synchronized with the camera
output signal.
External video signals
The video signals applied on the external video inputs are returned to the camera. Apply the
external video signal according to the following table:
Main video output connectors
SD video outputs
*) These signals are only available when the optional LDK 4531/30 High Quality SD board is
installed.
Selected camera

video mode
External video input

(Ext1, 2 or 3)
Output on the

camera adapter
1080p50/59 576i50 or 480i59.94 1080i50/59
1080p50/59 1080i50/59
720p50/59 no signal
1080i50/59 no signal
720p50/59 576i50 or 480i59.94 1080i50/59
1080p50/59 no signal
720p50/59 720p50/59
1080i50/59 no signal
1080i50/59 576i50 or 480i59.94 1080i50/59
1080p50/59 no signal
720p50/59 no signal
1080i50/59 1080i50/59
Connector Signal or function
HD-SDI A (2x) 2x BNC, 0.8 Vpp, 75 , SMPTE 292M (1.5 Gbit/s) with embedded audio
HD-SDI B (2x) 2x BNC, 0.8 Vpp, 75
, SMPTE 292M (1.5 Gbit/s)
HD-SDI C (2x) 2x BNC, 0.8 Vpp, 75 , SMPTE 292M (1.5 Gbit/s)
Live/Effect (2x) 2x BNC, 0.8 Vpp, 75 , SMPTE 292M (1.5 Gbit/s) with embedded audio
Connector Signal or function
SD-SDI-1 BNC, 0.8 Vpp, 75 , SMPTE 259M (270 Mbit/s) *)
SD-SDI-2 BNC, 0.8 Vpp, 75 , SMPTE 259M (270 Mbit/s) *)
