52 8949MDA-CXF/-SXF — Instruction Manual
Specifications
Attenuation Requirements
Some shorter length cable runs will require attenuation to prevent over-
driving the receiver causing bit errors to occur on the fiber link. Use the fol-
lowing guidelines for adding attenuation:
• The Dual Transmitter requires no attenuation between fiber transmitter
and receiver connections at any cable lengths.
• All CWDM devices used in a point-to-point configuration with a cable
run from 0-20 km (12.4 miles), must be attenuated by 5 dB between
fiber transmitter and receiver connections.
• CWDM devices used with 8939FCA modules for a mux/demux config-
uration with a cable run from 0-12 km (7.5 miles), must be attenuated
by 3 dB between 8939CFA COM ports.
Table 7. SFP Transmitter/Transceiver Fiber Optic Submodule Specifications
Model Number SFP-13103G-M1DTX SFP-13103G-M1TRX
Wavelength 1 1310 nm 1310 nm
Wavelength 2 1310 nm N/A
Transmit channels 2 1
Connector type LC
Fiber support Single-mode
Data rate 143 Mb/s to 2.97 Gb/s
Power output -5 to 0 dBm (-2dBm typical)
Maximum distance 10 km
1
1 The 1310 nm Dual Transmitter (SFP-13103G-M1DTX) and Transceiver (SFP-13103G-M1TRX) require no attenu-
ation between fiber transmitter and receiver connections at any length.
Maximum distance 20 km
