GUIDE TO INSTALLATION AND OPERATION
36 | DEC-1023
AUDIO
EMBEDDING
CHANNELS 1234 TO
[OFF, GRP 1, GRP 2, GRP 3, GRP 4]
CHANNELS 5678 TO
[OFF, GRP 1, GRP 2, GRP 3, GRP 4]
* Available with Audio
Card connected
OUTPUT MIXERS
CHANNEL 1
OPERATION MODE
[OFF, A, SUM(A+B), MIX]
CHANNEL 2
OPERATION MODE
[OFF, A, SUM(A+B), MIX]
ABUS
[A1, A2]
CHANNEL
SELECT
[1, 2, 3, …. 16]
LEVEL
[-96, -95, …. 0] (dB)
MUTE
[OFF / ON]
CHANNEL 3
OPERATION MODE
[OFF, A, SUM(A+B), MIX]
SOURCE
A
ABUS
[A1, A2]
CHANNEL
SELECT
[1, 2, 3, …. 16]
SOURCE
B
ABUS
[A1, A2]
CHANNEL
SELECT
[1, 2, 3, …. 16]
SUM (A+B) LEVEL
-6, -3, 0 dB
MUTE
[OFF / ON]
CHANNEL 8
OPERATION MODE
[OFF, A, SUM(A+B), MIX]
SOURCE
A
ABUS
[A1, A2]
CHANNEL
SELECT
[1, 2, 3, …. 16]
LEVEL
[-96, -95, …. 0] (dB)
SOURCE
B
ABUS
[A1, A2]
CHANNEL
SELECT
[1, 2, 3, …. 16]
LEVEL
[-96, -95, …. 0] (dB)
MUTE
[OFF / ON]
BLANKING VBI
(10-20)
[PASS, BLANK, PROC, DECOD, USER]
(DEC-1023 525)
VBI
(6-22)
[PASS, BLANK, PROC, DECOD, USER]
(DEC-1023 625)
INPUT LOSS
[KILL, BLACK, FREEZE FIELD, PASS]
* Available with Frame Sync Option
TIMING FRAME
DELAY
[0, 1, 2]
* Available with Frame Sync Option
VERTICAL
[0, 1, 2, …. 523, 524] (lines)
(525)
* Available with Frame Sync Option
[0, 1, 2, …. 623, 624] (lines)
(625)
* Available with Frame Sync Option
HORIZONTAL
[0, 0.037, 0.064, …. 63,5] (us)
(525)
[0, 0.037, 0.064, …. 64] (us)
(625)
