66
Switcher Products — Protocols Manual
Section 2 — Editor Protocol
Mode Byte — M/E
The format of the Transition Mode byte for an M/E as used by both
Kalypso and Zodiak systems is provided in
.
Mode Byte — DSK (Zodiak Only)
The format of the Transition Mode byte for the DSK as used by Zodiak
systems is provided in
Table 56. Transition Mode Byte Format – M/E
Bit
7
6
5
4
3
2
1
0
0
X
X
X
0
X
X
X
1 = KEY 2 on
1 = KEY 1 on
1 = BKGD on
1 = Key Priority on
1 = Key 4 on
a
a
New bit assignment associated with Kalypso and Zodiak
1 = Key 3 on
Table 57. Transition Mode Byte Format – DSK
Bit
7
6
5
4
3
2
1
0
0
X
X
X
0
X
X
X
1 = DSK 2 on
1 = DSK 1 on
1 = BKGD on
1 = Key Priority on
1 = DSK3 on
a
a
New bit assignment associated with Zodiak
