Disassembling the PDR100
PDR 100 9GB Disk Drive Upgrade
5
Disassembling the PDR100
This section covers the disassembly required to prepare the PDR100 for
installation of the new disk drives and tray. The tasks described are removal of:
• the bottom drive tray screws
• the top covers
• the Reference Genlock and RS-422 boards
• the power supply shield
• the old disk drive cables
• the fan tray
• the old LED cables (if they don’t have EMI suppression beads)
• the old disk drive tray with its drives.
