Electrical Specifications
Profile Video File Server Installation A-9
Table A-11. Analog Audio
Characteristics Description
Through Gain Requirement: 1
±
1 dB
Supplemental Data:Non-mix mode each of
four channels
Frequency Response Requirement: 20 Hz to 20 kHz, with between +0.5 dB, -2 dB
maximum deviation from flatness at 48 kHz
sample rate
Input Impedance Supplemental Data:600
Ω
or 20 k
Ω
each channel
Input/Output Signal Levels Supplemental Data:Nominal Line Level: 0 dBu
Nominal Peak Line Level: +9 dBu
Digital Clipping: +18 dBu (16-bit quantization)
THD+N at 1020 Hz and 60 Hz Requirement: -70 dBm (0.031%) at +9dBu input
Table A-12. Digital Audio
Characteristics Description
Bit Rate Supplemental Data:270 Mb/S
Return Loss Supplemental Data:15 dB from 5 MHz to 270 MHz
Input Impedance Supplemental Data:75
Ω
Output Amplitude Requirement:
800
mV p-p
, ±
80 mV.
Output DC Level Requirement: 0 V,
±
0.5 V
Output Rise and Fall Time Requirement: 400 pS to 1000 pS between 20% and 80%
Jitter Requirement:
≤
either 0.2ui or 720 pS p-p
Table A-13. Profile Video File Server Power Source
Characteristics Description
Electrical Rating Requirement: 100 -240V, 50/60 Hz, 10A maximum
Supply Type Supplemental Data:Single Phase
Supply Connection Supplemental Data:Detachable cord set
Power Consumption Supplemental Data:<600 VA
