8.4 Cycles for milling pockets,
studs and slots
Overview
Cycle
Soft key
4 POCKET MILLING (rectangular)
Roughing cycle without automatic pre-positioning
213 STUD FINISHING (rectangular)
Finishing cycle with automatic pre-positioning,
2nd set-up clearance
5 CIRCULAR POCKET
Roughing cycle without automatic pre-positioning
214 CIRCULAR POCKET FINISHING
Finishing cycle with automatic pre-positioning,
2nd set-up clearance
215 CIRCULAR STUD FINISHING
Finishing cycle with automatic pre-positioning,
2nd set-up clearance
3 SLOT MILLING
Roughing/finishing cycle without automatic pre-
positioning, vertical depth infeed
