HEIDENHAIN iTNC 530
613
1
1
.1
1 Pr
eassigned Q
P
ar
amet
ers
Tool axis: Q109
The value of Q109 depends on the current tool axis:
Spindle status: Q110
The value of Q110 depends on which M function was last
programmed for the spindle:
Tool axis
Parameter value
No tool axis defined
Q109 =-1
X axis
Q109 =0
Y axis
Q109 =1
Z axis
Q109 =2
U axis
Q109 =6
V axis
Q109 =7
W axis
Q109 =8
M Function
Parameter value
No spindle status defined
Q110 =-1
M3: Spindle ON, clockwise
Q110 =0
M4: Spindle ON, counterclockwise
Q110 =1
M5 after M3
Q110 =2
M5 after M4
Q110 =3
