32
12.1 Functions for Multiple Axis Machining ..... 382
12.2 The PLANE Function: Tilting the Working Plane (Software Option 1) ..... 383
Introduction ..... 383
Define the PLANE function ..... 385
Position display ..... 385
Reset the PLANE function ..... 386
Defining the machining plane with space angles: PLANE SPATIAL ..... 387
Defining the machining plane with projection angles: PROJECTED PLANE ..... 389
Defining the machining plane with Euler angles: EULER PLANE ..... 391
Defining the working plane with two vectors: VECTOR PLANE ..... 393
Defining the machining plane via three points: PLANE POINTS ..... 395
Defining the Machining Plane with a Single, Incremental Space Angle: PLANE RELATIVE ..... 397
Tilting the working plane through axis angle: PLANE AXIAL (FCL 3 function) ..... 398
Specifying the positioning behavior of the PLANE function ..... 400
12.3 Inclined-Tool Machining in the Tilted Plane ..... 405
Function ..... 405
Inclined-tool machining via incremental traverse of a rotary axis ..... 405
12.4 Miscellaneous Functions for Rotary Axes ..... 406
Feed rate in mm/min on rotary axes A, B, C: M116 (software option 1) ..... 406
Shorter-path traverse of rotary axes: M126 ..... 407
Reducing display of a rotary axis to a value less than 360°: M94 ..... 408
Automatic compensation of machine geometry when working with tilted axes: M114 (software option 2) ..... 409
Maintaining the position of the tool tip when positioning with tilted axes (TCPM): M128 (software option
2) ..... 410
Exact stop at corners with nontangential transitions: M134 ..... 413
Selecting tilting axes: M138 ..... 413
Compensating the machine’s kinematics configuration for ACTUAL/NOMINAL positions at end of block: M144
(software option 2) ..... 414
12.5 Peripheral milling: 3-D radius compensation with workpiece orientation ..... 415
Function ..... 415
12 Programming: Multiple Axis Machining ..... 381
